Manual Angle Table Angle Meter Arc Swing Table Swing Platform PT - SD4027

One dimensional manual angular position table with common light load

Driven by worm gear and worm structure, high-resolution precise angle adjustment can be carried out by rotating the hand wheel. It is easy to operate and has good bearing capacity. It is suitable for the occasions requiring precise arc swing angle. Light load angle table adopts linear arc rail structure or dovetail arc rail structure, which is suitable for light load occasions.

The ordinary manual angle table is driven by worm wheel and worm structure. It can adjust the precise angle with high resolution by rotating the hand wheel. It is easy to operate and has good bearing capacity. It is suitable for the occasions requiring precise arc swing angle. Light load angle table adopts linear arc rail structure or dovetail arc rail structure, which is suitable for light load occasions.

There are mounting screw holes at the bottom of the product, which can be directly connected with other countertops for assembly.

Product parameters:

Product dimension drawing:
