Z-Axis Manual Fine Adjustment Double Guide Lifting Stage Runs Smoothly PT-SD407

The precision manual lifting table PT-SD407 uses a double-guide rail over-positioning structure, which ensures smooth and comfortable operation. The main material is hard aluminum alloy, with black oxide treatment on the surface, high precision, good wear resistance and beautiful appearance. Differential head drive, quantitative reading, more accurate measurement. The base and table have connection holes with standard hole spacing, which can be combined with other displacement tables.

Manual Lifting Stage Product features:

1. The guide rail is a high-quality linear ball bearing pair;

2. Double guide rail over-positioning structure ensures smooth and comfortable movement and high accuracy;

3. Micrometer head drive, quantitative reading;

4. There are standard connection holes on the table, which are convenient for fixed connection. There are 12mm diameter long holes, which can directly fix the support rod.

Manual Lifting Stage Product Specifications:

Manual Lifting Stage Product Dimension Map:

Application areas:

Optical measurement, fine tuning displacement, visual alignment, digital imaging, instrumentation, mechanical equipment, medical equipment, semiconductor manufacturing, mold manufacturing, mechanical gripper, engraving machine, printing machine, laminating machine, 3D printer, automatic feeder, etc.

PDV product advantages:

1. Precision: achieve the precision required by customers at a reasonable price, which can fully meet the needs of high-precision scientific research institutions and mid-range precision industrial students in fine tuning;

2. Safety: It has the safety to withstand the test of time and not be subject to environmental changes;

3. Durability: Our products include stainless steel profile, aluminum profile and other series of profile products, which can withstand long time and heavy load in the production process. Especially in the field of FA, our five-dimensional and six-dimensional adjustment frames have longer service life and more convenient adjustment;

4. Diversification: In order to meet the different needs of different customers, we can adjust a series of products such as the length and size of the platform travel and the size of the table, and the platform can be combined into four-dimensional, five-dimensional and six-dimensional multidimensional platforms to meet the adjustment of different directions and angles;

5. Operability: Our product design is based on the customer's position, and different products are designed according to different customer's use occasions, which is very convenient to use;

6. After-sales service: Our delivery time is shorter, after-sales maintenance is faster, and the company has professional after-sales service personnel to respond quickly, so that you have no worries.

Beijing PDV Instrument Co., Ltd is a collection of optics, precision machinery, automatic control technology independent high-tech research and development enterprises. Since 2005, we have been serving the scientific research institutes and universities. We have developed the hardware and software system (optical path construction, software development, mechanical circuit design, etc.) according to the needs of customers. Through long-term unremitting efforts, the process of building the system to control the optical path and excellent service to customers, we’ve grown into a well-known manufacturer among scientific research, colleges and universities, machinery automation and many other areas.

The company designs and produces telephoto lens, automatic mechanical console, manual console, ultra brightness light source and other products. The products focus on modularization and integration, and have formed mass production. They have complete specifications and good quality. At the same time, they provide customized services. With excellent quality, the products are widely used in electronic and precision industrial testing, laboratory and measuring instrument industries, scientific research institutions, and exported to overseas markets such as Japan, South Korea, Europe and the United States.

The company has strong technical force and has a group of professional teams engaged in R & D, production and sales of optoelectronic products for a long time. It has extensive professional experience in displacement precision adjustment, motion control, precision image measurement and so on.

We hope to become your reliable partner with perfect products and reasonable price, and win your support.
