XYR Motorized Multi-Axis Displacement Stage XY Axis Translation 360 ° Rotation
This motorized multi-axis is composed of a motorized XY linear stage PT-XY100 and a motorized rotary stage PX110-100. motorized XY linear stage PT-XY100, XY axis travel 100mm, table size 300 * 300mm. The motorized rotary stage PX110-100 can continuously rotate 360 degrees, with a table diameter of 100mm. There are two transmission ratio specifications available for selection: 90:1, or 180:1.
Motorized XY linear stage PT-XY100 Product parameter specifications:
| Model Number | PT-XY100 | |
| Structure | Travel Range(mm) | 100mm |
| Platform Size | 300mm x 300mm | |
| Screw Guide | 4 | |
| Travel Guide | Precise Crossed Roller Bearing | |
| Stepper Motor | 42(1.8°) | |
| Material | Aluminum Alloy | |
| Surface Preparation | Black-Anodized | |
| Load Capacity(kg) | 50 | |
| Weight(kg) | 8.3 | |
| Accuracy | Resolution(μm) | 20(Non MS), 2.5(8 MS) |
| Max Velocity | 40mm/sec | |
| Repeatability(μm) | 2 | |
| Absolute Accuracy(μm) | 3 | |
| Straightness(μm) | 5 | |
| Moving Parallelism(μm) | 15 | |
| Pitching | 50" | |
| Yawing | 25" | |
| Backlash(μm) | 2 | |
| Lost Motion(μm) | 2 | |
| Accessory | Installing Grating Ruler (Optional) | |
| Reloading Servo Motor (Optional) | ||
Motorized Rotation Stage PX110-100 Parameter Specifications:
| Model Item | PX110-100 | |
| Structure | Rotation Range | 360° |
| Platform Size | φ100mm | |
| Transmission Ratio | 180∶1 or 90:1 | |
| Drive Mechanism | Worm Gear | |
| Travel Guide | Bearing | |
| Stepper Motor (1.8°) | 42BYG | |
| Material Surface | Aluminum Alloy (Black-Anodized) | |
| Central Load | 45kg | |
| Weight | 1.7kg | |
| Accuracy | Design Resolution | 0.01°(Non-MS Driver) |
| 0.0005°=1.8″(20MS Drive) | ||
| Max Velocity | 25°/sec | |
| Repeatability | 0.005°=18″ | |
| Absolute Accuracy | 0.01°=36″ | |
| End jump accuracy | 15μ | |
| Backlash(μm) | 0.005°=18″ | |
| Eccentricity | 5μ | |
| Lost Motion(μm) | 0.005°=18″ | |
| Parallelism | 80μ | |
|
|
