    Displacement Aluminium Alloy Manual Xyz Stage Mobile Platform

    Ask Lasest Price
    Brand Name : PDV
    Model Number : TZ-II
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Delivery Time : 1-2 weeks
    • Product Details
    • Company Profile

    Displacement Aluminium Alloy Manual Xyz Stage Mobile Platform

    Lens Adjusting Frame Manual Displacement Stage Mobile Platform


    TZ-II (adjusting frame) price does not include lens


    High Precision Manual Linear stage: PT110-50-100H/CH


    Model Number

    PT110-50-100H

    PT110-50-100CH

    PlatformSize

    100mm×100mm

    100mm×100mm

    Drive Mode

    Micrometer
    Head in Side

    Drive Position

    Central Drive

    Lateral Drive

    Travel

    50mm

    50mm

    Minimum Scale

    0.01mm

    0.01mm

    Minimum Adjust Distance

    0.002mm

    0.002mm

    Travel Guide

    Crossed Roller Bearing

    Load capacity

    40kg

    40kg

    Straightness

    Pitching

    25″

    25″

    Yawing

    15″

    15″

    Parallelism

    10μ

    10μ

    Driving Parallelism

    15μ

    15μ

    Weight

    1.1kg

    1.1kg

    Material– Finish

    Aluminum Alloy - Black-Anodized


    PT110-50-100H Product Dimension Drawing:


    PT110-50-100CH Product Dimension Drawing:


    Precision Manual Goniometer Stage PT-SD310


    Model Number

    PT-SD310

    Platform Size

    100mm×100mm

    Angle Range

    ±15°

    Height of turning center

    125.5 mm

    Deviation of turning center

    φ0.05 mm

    Driving Mode

    Worm drive

    Guide form

    V-guide + ball

    Driving position

    central drive

    Min Scale

    Min Reading

    5′

    Min Adjustment

    30″(consult)

    Pendulum

    200″

    tilt

    200″

    Load bearing

    5kg

    Dead weight

    1.75kg

    Material

    Aluminium alloy

    surface treatment

    Anodizing blackening


    PT-SD310 Product Dimension Drawing:


    Precision Manual Rotary stage PT-R125


    Model Number

    PT-R125

    Platform Size

    Φ125

    Min Reading

    32″/circle

    Travel Range

    Coarse: 360° , Fine: ±5°

    Travel Guide

    Duplex Bearing

    Load Capacity

    5kgf(49N)

    Parallelism

    20μm

    Eccentricity

    50μm

    Weight

    0.85kg

    Material– Finish

    Aluminum Alloy - Black-Anodized
