15 ° Adjustment Light Load One Dimensional Manual Arc Swing Stage PT-SD4027

PT-SD4027 one-dimensional manual arc swing table has a table size of 40mm and a swing center distance of 27mm, which is a light load angle position table. Driven by worm gear and worm structure, high resolution precision angle adjustment can be carried out by rotating the hand wheel, which is convenient to operate and has good bearing capacity, and is suitable for occasions requiring precision arc swing angle. The light load arc swing table adopts linear arc rail structure, which is suitable for use in light load situations.

There are mounting screw holes at the bottom of the product, which can be directly connected to other worktops for assembly and use.

Product features of manual arc swing stage:

1. Precision grinding worm gear transmission is adopted, with small clearance and smooth movement and high sensitivity.

2. Adopt high-precision arc V-type roller guide rail, with high strength, strong load capacity and good durability.

3. The standard installation hole position can be used alone or matched with other products of our company to form a multi-dimensional motion system.

Product specification of manual arc swing stage

Product dimension drawing of manual arc swing stage

Application examples of goniometer slide (angle stage):

1. LCD projector prism positioning and loading. Apply to fiber adjustment. Fiber coupling.

2. Optical fiber positioning, optical communication system products and testing equipment.

3. Semiconductor related production equipment and inspection and evaluation equipment, measuring device, inspection device, processing machine, precision mechanical equipment, led processing equipment, laser cavity position adjustment.

Beijing Paidiwei Instrument Co., Ltd. produces: high-precision displacement table, electric slide table, fine-tuning table, angle position table, six-dimensional adjustment frame, cross guide rail adjustment frame, multi-dimensional displacement table, cross guide rail slide table, arc pendulum table, optical adjustment frame, manual displacement table, etc. Welcome to call for consultation.
