60×60mm Fine Adjustment Of Optical Experiment Manual Angle Tilting Platform​ PT-SD60115

The main material of this manual angle tilting platform product is made of high-quality aluminum alloy, which is guided by dovetail arc rail and driven by worm gear. The table is stable and reliable in operation, with high sensitivity. The product is suitable for fields with high requirements for manual angle adjustment. The installation holes of various standard hole positions on the table are suitable for different needs. The lower standard fixing hole can connect it with other sliding tables to form a multi-dimensional sliding table.

Scope of application:

Optical equipment, measuring devices, semiconductor manufacturing equipment, testing machines, microscopes, handling machines, processing machines, printing machines and others.

Product specification of manual angle tilting platform

Product dimension drawing of manual angle tilting platform

Product details

1. Handle and locking

The handle is made of metal material, which can be used in complex environment and is more durable and corrosion resistant.

2. Laser engraving

The scale is clear, durable, friction-resistant, not easy to drop words, and the measurement is more accurate.

3. Work table

Made of high-density aluminum alloy, light weight, suitable for built-in and other devices.

Product use environment

This series of products are composed of high precision parts, please avoid use in extremely high temperature, extremely low temperature, extreme temperature changes in direct sunlight, high humidity, high dust, high vibration, high impact and easy fog environment.
Ambient temperature: 10 °C to 50°C Recommended temperature: 22+5°C

Maximum product load

Load refers to the force that the platform can bear when the center of gravity of the workpiece is located in the center of the platform. The center of gravity of the bearing object on the horizontal platform does not exceed the table in order to ensure the accuracy of the movement of the platform and service life, please check the allowable load of the platform when the platform is used.
